1U 24 Port CAT6 Shielded FTP Network Patch Panel 110 Dual-use CologneTerminals
The 1U 24 port CAT6 6 type shielding (FTP) copper patch panel 110 Cologne terminals are applied to the level of the equipment or equipment terminations, as well as the centralized point of mutual connection terminations.
Features
1.Standard 19-inch rack type, standard 1U height, meet and exceed the relevant standards.
2.The wiring terminal of the distribution frame is Kelon and 110 dual terminal;
3.The terminals of the distribution frame are not integrated design and have stable performance,which can be used for quick wining without any module;
4.The whole distribution frame is metal structure, and the wiring terminals are equipped with a fully enclosed metal shielding layer;
5.The end of each shielded cable is equipped with all-metal cable clip to ensure the shielding and grounding performance of the cable;
6.The distribution frame has a single inch design, which ensures the shielding and grounding performance of the whole distribution frame.
Applications
CAT6 shielded (FTP) copper patch panel provided by Shenzhen Haoyu Telecommunication Co., Ltd. (Haoyu) can be applied to the level of equipment or equipment terminal, as well as the mutual matching terminal of the centralized point.sturdy and easy to install design,reduce installation and operation costs,large front identification space convenient port identifcation, easy to manage.
|
1U 24 Port CAT6 Shielded FTP Network Patch Panel 110 Dual-use CologneTerminals |
|
|
Rated current |
1.5A |
|
Contact resistance |
Max 100mΩ(500VDC) |
|
Insulation resistance |
Min 1000MΩ |
|
Compressive strength |
750VAC(60Hz/min) |
|
Storage temperature |
-40°C to +70°C |
|
Operating temperature |
-20°C to +60°C |
|
IDC Shell material |
PBT |
|
Panel frame material |
SPCC,Black or industrial gray, electrostatic powder coating |
|
Plug service life |
≥750 Times |
|
IDC life |
≥200 Times |
|
Contact material |
Phosphor bronze, The thickness of the0.3mm |
|
IDC Contact material |
Phosphor bronze, Surface of nickel plating |
|
Number of rules |
23-24AWG |
